TOPFLY TSR1-B (BLE 5.0 Relay)
TSR1-B (BLE 5.0 Relay)
It’s designed to change the open/closed status of circuits, commonly used for cutting off fuel pump, starter of engine and air conditioning. It can be triggered remotely by sending commands to tracker then to the relay via BLE, or directly from phone to relay.
.
Technical Specifications
Dimensions:21mm*51mm*10mm (0.69” *0.17” *0.32”)
Weight:20g±1g (0.7oz)
Operating Voltage:DC 7V~32V
Standby Current:< 1 mA @ 12V&24V
Trigger Current:17 mA@12V / 10 mA@24V
Operating Temperature:-30℃ ~ +80℃ (-22°F ~ 176°F)
Power Output:+4 dBm
Transmission Range:Up to 300m (Open Field)
- Nuevo
TOPFLY TSTH1-B (BLE 5.0 Temperature & Humidity Sensor)
TSTH1-B
It collects the temperature and humidity of the environment and transmits the data via BLE to trackers or BLE hub, then transmitted to server finally. It is designed for the demands of the environmental monitoring industry to resolve losses caused by unexpected and unfriendly temperature and humidity changes.
.
General Specifications
Battery: replaceable CR2477 battery (1000mAh)
Operating temperature: -30℃ ~ +80℃ (-22°F ~ 176°F)
Temperature accuracy (0-60 ℃) : ± 0.2 ℃ (Typical long-term drift <0.02 ° C / year)
Humidity accuracy (10% -90%): ± 2% RH (long-term drift rate <0.25% RH / Y)
Transmission range: up to 300m (open field)
Others: Front light sensor
- Nuevo
TOPFLY SOLARGUARD X200 (4G/3G/2G) SOLAR PANEL & BLE 5.1
SOLARGUARDX-200
This Solar GPS Padlock is designed and developed for outdoor asset tracking telematic structures. It has a long-life battery, solar-powered with high charging efficiency, and is suitable for tracking and safeguarding assets such as containers, trailers, trucks, etc. The solar-powered E-lock for cargo reports alarms to the server for events of rope cutting, locking, and unlocking. Furthermore, our padlock can be opened both remotely and in the near field by either RFID and BLE or with commands via network and SMS.
.
FREQUENCY
LTE FDD Cat 4 or Cat 1 (default):
BB1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/ B20/B25/B26/B28/B66
LTE TDD Cat 4 or Cat 1(default): B34/B38/B39/B40/B41
WCDMA: B1/B2/B4/B5/B6/B8/B19 GSM/EDGE: 850/900/1800/1900MHz
- Nuevo
TOPFLY SOLARGUARD X100 (4G LTE) SOLAR PANEL & BLE 5.1
SOLARGUARDX 100
This Solar GPS Padlock is designed and developed for outdoor asset tracking telematic structures. It has a long-life battery, solar-powered with high charging efficiency, and is suitable for tracking and safeguarding assets such as containers, trailers, trucks, etc. The solar-powered E-lock for cargo reports alarms to the server for events of rope cutting, locking, and unlocking. Furthermore, our padlock can be opened both remotely and in the near field by either RFID and BLE or with commands via network and SMS.
.
FREQUENCY
LTE FDD Cat M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85
LTE FDD Cat NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85
GSM/EDGE:850/900/1800/1900 MHz
- Nuevo
TOPFLY TLP2-SFB (4G LTE) SOLAR PANEL & BLE 5.0
TLP2-SFB (4G LTE)
It’s suitable for tracking and monitoring assets such as containers, trailers, trucks, etc. It reports alarm to server for events of start moving, stop moving, device removal, etc. It works with BLE temperature sensor, door sensors etc.
.
FREQUENCY
FDD: B1/B2/B3/B4/B5/B8/B12/B13/B19/B20/B25/B28
TDD: B39 (Cat M1 only)
EGPRS: 850/900/1800/1900MHz
- Nuevo
TOPFLY TLP1-SF (4G LTE) SOLAR PANEL
TLP1-SF – 4G
solar powered gps tracking device that is designed to track the location of assets/trailers/trucks with big intenal battery and solar powered.Its battery can obtain power from solar panel to avoid maintenance cost.
.
FREQUENCY
FDD: B1/B2/B3/B4/B5/B8/B12/B13/B19/B20/B25/B28
TDD: B39 (Cat M1 only)
EGPRS 850/900/1800/1900MHz
- Nuevo
TOPFLY TLP1-LF (4G LTE)
TLP1-LF (4G LTE)
When frequent location update is not required for stationary asset, TLP1-LF is the one you go with. 1-4 updates per day will keep the battery at a healthy consuming rate for long term tracking.
.
Network/Operating Band
FDD: B1/B2/B3/B4/B5/B8/B12/B13/B19/B20/B25/B28
TDD: B39 (Cat M1 only)
EGPRS 850/900/1800/1900MHz
- Nuevo
TOPFLY TLP1-P (4G LTE)
TLP1-P (4G LTE)
A tracker that has an built-in long-life rechargeable battery could be used in varies flexible scenario such as tracking people/vehicle/parcels/luggage. It can be easily hidden with its compact size. Keep eyes on your properties whereabouts and ensure the recovery when lost.
.
FREQUENCY:
FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28
TDD: B39 (Cat M1 only)
EGPRS 850/900/1800/1900MHz
